Machine Learning Optimization - Stochastic Gradient Descent

Table of Contents

0: Introduction

1: Crash Course: Gradient Descent

3: Variance Reduction Techniques

4: SARAH and ADAM Algorithms

Previous: ML Optimization Splash Page

Stochastic Gradient Descent

Stochastic methods are common in many areas of computational mathematics and are desirable for improving computational performance by leveraging random operations. A stochastic approach to gradient descent is a natural extension; we want to speed up an inherently slow but robust method for training our machine learning models.

The core concept of stochastic gradient descent is straightforward -- rather than performing a full gradient calculation at each timestep of gradient descent, we can sample individual gradients ∇fi\nabla f_i's (where ii is selected uniformly at random from 1,...n1,...n) in lieu of computing the full gradient ∇f\nabla f. We use a randomly sampled ∇fi\nabla f_i at each step as a general approximation for the full gradient ∇f\nabla f in the descent algorithm to step toward the solution at significantly reduced computational cost, with the concession that the step is an approximation.

See appendix for more details on stochastic gradient calculation.

So, we would like to show that this randomly sampled gradient is a valid estimator of the true gradient.

SGD Algorithm

For stochastic descent, we want to consider the following problem, minimizing the average of functions, where ff is our objective function, a function of our model parameters θ\theta.

minf(θ)θ=Δ1n∑i=1nfi(θ)\begin{aligned} \underset{\boldsymbol{\theta}}{\text{min}f(\boldsymbol{\theta})}\overset{\Delta}{=}\frac{1}{n}\sum_{i=1}^{n}{f_{i}(\boldsymbol{\theta})} \end{aligned}

Taking the gradient of this objective function ff gives

∇f(θ)=1n∑i=1n∇fi(θ)\begin{aligned} \nabla f(\boldsymbol{\theta}) = \frac{1}{n}\sum_{i=1}^{n}{\nabla f_{i}(\boldsymbol{\theta})} \end{aligned}

Stochastic gradient descent (SGD) is defined as the following.

θk+1=θk−αk∇fik(θk)\begin{aligned} \boldsymbol{\theta}_{k+1}=\boldsymbol{\theta}_{k}-\alpha_{k} \nabla f_{i_{k}}(\boldsymbol{\theta}_{k}) \end{aligned}

where ik∈{1,...,n}i_{k} \in \{1,...,n\} is an index chosen uniformly at random for an iteration kk.

NOTE

SGD cannot converge with a fixed step size; instead it must use a diminishing step size that satisfies lim αk=0k→∞\underset{k \rightarrow \infty}{\text{lim }\alpha_{k} = 0} and ∑k=1∞αk=∞\overset{\infty}{\underset{k=1}{\sum}}{\alpha_{k}} = \infty. Hence learning rate is denoted with αk\alpha_{k}.

We want to determine whether ∇fik(θk)\nabla f_{i_{k}}(\boldsymbol{\theta}_{k}) is a valid estimator for the true gradient ∇f(θk)\nabla f(\boldsymbol{\theta}_{k}), so we are interested in its expectation. Since iki_k is selected uniformly at random, the following expectation holds.

E[∇fik(θk)]=∑i=1nP(i=ik)∇fik(θk)=1n∑i=1n∇fik(θk)=∇f(θk)\begin{aligned} \mathbb{E}[\nabla f_{i_{k}}(\boldsymbol{\theta}_{k})] = \sum_{i=1}^{n}{P(i=i_{k}) \nabla f_{i_{k}}(\boldsymbol{\theta}_{k})} = \frac{1}{n} \sum_{i=1}^{n}{ \nabla f_{i_{k}}(\boldsymbol{\theta}_{k})} = \nabla f(\boldsymbol{\theta}_{k}) \end{aligned}

So, an individual gradient is an unbiased estimator for the full gradient, a fundamental principle to stochastic gradient descent.

This presents a great computational advantage -- since we are selecting an individual gradient at random ∇fik\nabla f_{i_{k}}, ik∈{1,...,n}i_{k} \in \{1,...,n\} for each iteration of SGD, it doesn't matter what the sample size of our data is. The sample size of the data nn could be very large and an SGD computation will "cost" the same per iteration.

SGD
Compare

On the left, we see the SGD optimizer algorithm stepping the parameters toward the solution in some obviously approximate ways. On the right, we also impose other algorithms that we will revisit later that use variance reduction technniques for comparison.

Since we are now taking steps in our descent algorithm using approximations of the gradient, we are going to be taking steps only approximately in the direction of the optimum.

SGD Convergence and Variance

The inexactness of the steps that we have now introduced to gradient descent is variance. Variance in our algorithm's steps can in fact slow the algorithm down in its own right (we are only approximately stepping in the right direction after each step), so we must take additional considerations to how we approach the development of SGD algorithms. First, we must be able to quantify the variance.

An analysis of convergence of SGD reveals how we quantify the variance in the algorithm's steps. The SGD algorithm can be rewritten as the following.

θk+1=θk−αk[∇f(θk)−(∇f(θk)−∇fik(θk))⏟wk]\begin{aligned} \boldsymbol{\theta}_{k+1}=\boldsymbol{\theta}_{k}-\alpha_{k} [\nabla f(\boldsymbol{\theta}_{k})-\underset{w_{k}}{\underbrace{(\nabla f(\boldsymbol{\theta}_{k})-\nabla f_{i_{k}}(\boldsymbol{\theta}_{k}))}}] \end{aligned}

We assume ff is convex and that ∇f\nabla f is Lipschitz continuous. First, we define wk=Δ∇f(θk)−∇fik(θk)\boldsymbol{w_{k}} \overset{\Delta}{=} \nabla f(\boldsymbol{\theta_{k}}) - \nabla f_{i_{k}}(\boldsymbol{\theta_{k}}). wk\boldsymbol{w_{k}} quantifies the error between the full gradient and a stochastic gradient at iteration kk.

Next, we take the conditional expectiation of wk\boldsymbol{w_{k}} given parameters θk\boldsymbol{\theta_{k}},

E[wk∣θk]=E[∇f(θk)−∇fik(θk)∣θk]=∇f(θk)−E[∇fik(θk)∣θk]⏟∇f(θk)=0\begin{aligned} \mathbb{E} [\boldsymbol{w_{k}} | \boldsymbol{\theta_{k}}] = \mathbb{E} [ \nabla f(\boldsymbol{\theta_{k}}) - \nabla f_{i_{k}}(\boldsymbol{\theta_{k}}) | \boldsymbol{\theta_{k}}] = \nabla f(\boldsymbol{\theta_{k}}) - \underset{\nabla f (\boldsymbol \theta_{k})}{\underbrace{\mathbb{E} [\nabla f_{i_{k}}(\boldsymbol{\theta_{k}}) | \boldsymbol{\theta_{k}}]}} = 0 \end{aligned}

We establish wk\boldsymbol{w_{k}} is conditionally unbiased as an assumption. Now we take the conditional variance and use the conditional unbiasedness assumption for the following.

Var(wk∣θk)=E[wkwkT∣θk]−E[wk∣θk]2⏟=0\begin{aligned} \text{Var}(\boldsymbol{w_{k}} | \boldsymbol{\theta_{k}}) = \mathbb{E} [\boldsymbol{w_{k}} \boldsymbol{w_{k}}^T | \boldsymbol{\theta_{k}}] - \underset{=0}{\underbrace{\mathbb{E} [\boldsymbol{w_{k}} | \boldsymbol{\theta_{k}}]^2 }} \end{aligned}

We can now use the Cauchy-Schwarz Inequality to show

∣∣Var(wk∣θk)∣∣≤E[∣∣wk∣∣2∣θk]≤σ2\begin{aligned} || \text{Var}(\boldsymbol{w_{k}} | \boldsymbol{\theta_{k}}) || \leq \mathbb{E} [||\boldsymbol{w_{k}}||^2 | \boldsymbol{\theta_{k}} ] \leq \sigma^2 \end{aligned}

So our conditional variance must be bounded by some constant variance σ2\sigma^2.

Next, we want to observe a sequence of θk\boldsymbol{\theta_{k}} generated by SGD after TT iterations, k∈{1,...,T}k \in \{1,...,T\}. Let θˉT=1T∑k=0T−1θk+1\bar{\boldsymbol{\theta}}_T = \frac{1}{T} \sum_{k=0}^{T-1}{\boldsymbol{\theta_{k+1}}} and α≤12L\alpha \leq \frac{1}{2L}.

Under these assumptions, we show the following convergence for SGD.

E[f(θˉT)−f(θ∗)]≤12αkT∣∣θ0−θ∗∣∣2+αkσ2\begin{aligned} \mathbb{E}[f(\bar{\boldsymbol{\theta}}_T)-f(\boldsymbol{\theta}^*)] \leq \frac{1}{2 \alpha_k T}|| \boldsymbol{\theta_0} - \boldsymbol{\theta^*} ||^2 + \alpha_k \sigma^2 \end{aligned}

If we select αk=1T\alpha_k = \frac{1}{\sqrt{T}}, we achieve a convergence rate of O(1T)\mathcal{O}(\frac{1}{\sqrt{T}}), which is an improvement over regular gradient descent. Note here, αk\alpha_k decays as we step, so the algorithm "slows down" as we proceed. The variance in the steps requires that our learning rate decays, which is generally undesirable.

We are able to quantify a bound for the variance of SGD, and we can now start to explore what different approaches we may take to reduce it.

Next: Variance Reduction Techniques
